Cygnet Machinery is a renowned manufacturer of Monolayer Blown Film Plants in Ahmedabad, India. A Monolayer Blown Film Plant is a type of extrusion system used to produce single-layer plastic films through a process known as blown film extrusion. The plant uses a single extruder to melt and extrude polymer resin, which is then formed into a thin tube of plastic film through a die. The tube is inflated with air to create a bubble, and as the bubble rises, it is cooled and stretched to the desired thickness and size. The film is then flattened and wound into rolls for further use or processing.
A Mono Layer Blown Film Plant is a type of machinery used in the production of plastic films through the blown film extrusion process. It is designed to produce a single layer of plastic film, typically made from materials such as LDPE (Low-Density Polyethylene), HDPE (High-Density Polyethylene), or LLDPE (Linear Low-Density Polyethylene). The film produced is used for a wide range of applications, including packaging, agricultural films, food wraps, and more.
| Specification | CM-MB-45 | CM-MB-55 | CM-MB-65 |
|---|---|---|---|
| Model | CM-MB-45 | CM-MB-55 | CM-MB-65 |
| Material To Be Processed | HM, LD, PBAT-BIO, HDPE | HM, LD, PBAT-BIO, HDPE | HM, LD, PBAT-BIO, HDPE |
| Screw Dia | 45mm | 55mm | 65mm |
| Barrel Feed Type | Groove Feed | Groove Feed | Groove Feed |
| L D Ratio | 30:1 | 30:1 | 30:1 |
| Film Thickness Range | 20 to 120 micron | 20 to 120 micron | 20 to 120 micron |
| Die | Spiral Type Die | Spiral Type Die | Spiral Type Die |
| Filter Type | Candle Filter / Screen Changer | Candle Filter / Screen Changer | Candle Filter / Screen Changer |
| Lay Flat Film Width Range | 200 to 800 mm | 300 to 1000 mm | 400 to 1500 mm |
| Maximum Output | 50 Kg/Hr | 65 Kg/Hr | 75 Kg/Hr |
| Winder | Single Station Surface Winder | Single Station Surface Winder | Single Station Surface Winder |
| Machine Connected Load | 38 KW (51 HP) | 47 KW (63 HP) | 59 KW (79 HP) |
| Dimensions (L x W x H) Approx. in Feet | 10 x 10 x 16 | 25 x 10 x 18 | 25 x 10 x 18 |
| Optional Attachment | Rotating Die | Rotating Die | Rotating Die |
| LDPE, LLDPE Attachment | HM, HDPE Attachment | HM, HDPE Attachment | |
| Double Station Winder | Double Station Winder | Double Station Winder |
